Rolec EVO 22kW EV Wall Charger – 3-Phase, Solar Enabled, OCPP

The ROLEC5013 EV charger from the Rolec EVO series delivers up to 22kW via a Type 2 universal socket. Designed for eco-conscious installs, it supports solar integration, dynamic load balancing, and tariff-aware charging via the Rolec EVO App.

IP54 and IK10 rated with PEN protection and OCPP 1.6J for full smart compatibility. Connectivity includes Wi-Fi, 4G, Ethernet, and Bluetooth. Includes 5-year warranty.

KEY FEATURES

• Charging Power: 22kW (32A, Three Phase)
• Charging Mode: IEC 61851-1 Mode 3
• Connector Type: Type 2 universal socket
• Adjustable current: 6A–32A
• Voltage Supply: 400V AC ±10%, 50/60Hz
• Connectivity: 4G LTE (Nano SIM), Wi-Fi 6, Ethernet, Bluetooth
• App: Free ROLEC EVO mobile app for full control
• Charging modes: Plug & Go, ECO (grid + solar), ECO+ (solar only)
• Dynamic Load Balancing (requires optional CT clamp kit)
• PME fault detection – no earth rod required
• Integrated 30mA Type A RCD & 6mA DC protection
• Compatible with smart tariffs and scheduling
• OCPP 1.6J compliance for third-party app integration
• LED status ring, RFID control, and analytics monitoring
• Colour / Finish Grey

Additional Information

• Dimensions (H x W x D) 260mm (W) x 260mm (H) x 112mm (D)
